0 degree service


Providing High Rate SEVIRI image data in near real time

0 degree NCOL
0 degree NCOL

The 0 degree service is the main mission of Meteosat Second Generation.

Last Updated

29 March 2023

Published on

29 April 2020

It provides High Rate SEVIRI image data, in 12 spectral bands, processed in near real-time to Level 1.5.

The SEVIRI instrument allows for a complete image scan (Full Earth Scan) once every 15-minute period. Each 15-minute period, or repeat cycle, consists of eight segments of image data, with the exception of the HRV channel, which has 24 segments. Each segment has 464 lines of image data.

The data are accompanied by the appropriate ancillary information that allows the user to calculate the geographical position and radiance of any pixel. Before distribution to the user, the data are compressed using lossless compression using the algorithms described in this Repository.

As well as the High Rate SEVIRI product, meteorological products are also generated and disseminated to the user community in near real-time. For a comprehensive list, consult the Product Navigator.

The nominal coverage of the prime MSG service — the geostationary service from the MSG satellite located at 0 degrees longitude — includes the whole of Europe, the Atlantic Ocean, all of Africa and at locations where the elevation to the satellite is greater than or equal to 10°.

A repeat cycle prologue file precedes the delivery of the image segments and a repeat cycle epilogue file follows after the delivery of the segments and contains final quality information for the image. The image segments are numbered and a fixed relationship between the image segment number and the line offset is established. The image segment numbering direction follows the radiometer scan direction.

Data access

For information on how to access 0 degree data see our How to access our data page.

Search the Product Navigator catalogue for full details on data access and dissemination.

Spectral channels

High Rate SEVIRI

High Rate SEVIRI image data consist of geographical arrays of various sizes of image pixels, each pixel containing 10 data bits, representing the received radiation from the earth and its atmosphere in the 12 spectral channels. Of these 12 spectral channels, 11 provide measurements with a resolution of 3 km at the sub-satellite point with the 12th, the High Resolution Visible (HRV) channel, providing measurements with a resolution of 1 km.

Example - MSG Channel 01 - VIS
Visible band centred on 0.6µm - Channel 1 (VIS 0.6)
Example - MSG Channel 02 - VIS
Visible band centred on 0.8µm - Channel 2 (VIS 0.8)
Example - MSG Channel 03 - NIR
Near-infrared band centred on 1.6µm - Channel 3 (IR 1.6)
Example - MSG Channel 04 - IR
Infrared band centred on 3.9µm - Channel 4 (IR 3.9)
Example - MSG Channel 05 - WV
Water Vapour band centred on 6.2µm - Channel 5 (WV 6.2)
Example - MSG Channel 06 - WV
Water Vapour band centred on 7.3µm - Channel 6 (WV 7.3)
Example - MSG Channel 07 - IR
Infrared band centred on 8.7µm - Channel 7 (IR 8.7)
Example - MSG Channel 08 - IR
Ozone band centred on 9.7µm - Channel 8 (IR 9.7: O3)
Example - MSG Channel 09 - IR
Infrared band centred on 10.8µm - Channel 9 (IR 10.8)
Example - MSG Channel 10 - IR
Infrared band centred on 12.0µm - Channel 10 (IR 12.0)
Example - MSG Channel 11 - IR
Carbon Dioxide band centred on 13.4µm - Channel 11 (IR 13.4: CO2)
Example - MSG Channel 12 - HRV
Broadband high-resolution visible band - Channel 12 (HRV)

Scan modes

The HRV channel supports a mode of operation known as Alternative HRV Scanning Mode Operations. In this mode it is possible to introduce a horizontal split into the HRV image, and separately specify the E-W offset of the HRV image window above and below the split.

From the start of MSG routine operations until 31 August 2005, the HRV scanning mode was fixed as follows:

  • Split position: Line 914
  • E-W offset for lower window: Chosen to east-justify the image
  • E-W position for upper window: Chosen to optimise the coverage of the European region

From 31 August 2005 onwards, the lower window shifted to follow the daily illumination. The configuration is as follows:

  • Between 00:00 and 14:00 UT the lower HRV window is east-justified so as to optimise the coverage of the Indian Ocean region.
  • Between 14:00 and 17:00 UTC the lower HRV window moves every hour, on the hour incrementally westwards, until in becomes west-justified.
  • Between 17:00 and 00:00 UTC the lower HRV window is west-justified to optimise the coverage of the Atlantic Ocean.

From 17 August 2018 onwards, for the FES prime mission, the upper window is shifted to the west position at 10:00 UTC every day (instead of 17:00 UTC previously) to allow for a better coverage of the Azores Islands. The current configuration is as follows:

  • Between 00:00 UTC and 10:00 UTC, the upper HRV window is at its nominal position centred on Europe (covers from 40-deg E longitude to 20-deg W longitude).
  • At 10:00 UTC the upper HRV window is shifted about 10-deg longitude in the westward direction.
  • Between 10:00 UTC and 00:00 UTC the upper HRV window is kept in the westward shifted position.
  • At 00:00 UTC the upper HRV window is shifted back to the normal position.
HRV window configuration animation

FES image Epilogue delay during eclipse season

The nominal Repeat Cycle for the Full Earth Scan Service is 15 minutes, split into ~12.5 min for the imaging and ~2.5 min for the calibration, retrace and stabilisation.

During the eclipse season, i.e. during weeks of March and the first weeks of April, an ‘Early Retrace’ is used. The Meteosat SEVIRI instrument retraces immediately after reaching the upper threshold. This is to avoid the instrument being heated up by the Sun, which can be reflected onto the instrument assembly.

Once every hour an ambient black-body calibration (BBCal) takes place and, additionally, a couple heated BBCal throughout the day. During the weeks of ‘Early Retrace’, these BBCal happen after the retrace, when the solar aspect angle is between 80.26 deg and 88.26 deg.

The complete image data, including the Epilogue, is therefore only available about 2 minutes later than in all other Repeat Cycles. This is a nominal behaviour.

Quality indicators

High Rate SEVIRI Image Product contains numerous image quality indicators. These indicators provide information on the completeness, geometric quality, radiometric quality, and timeliness of the Level 1.5 product, as well as information on the quality and completeness of the Level 1.0 Image from which the Level 1.5 Image Product was derived. See MSG Level 1.5 Image Product - Quality Indicators.

Service registration

Access to SEVIRI near real-time and offline data and products typically involves an initial registration process. For further information, please visit our Data Registration page, or register on the Earth Observation Portal.

Backup service

Mission swaps (transferring operations from one Meteosat satellite to another Meteosat satellite) are performed to ensure continuity of the 0 degree service in the event of a longer service outage. Such service outages may be caused by anomalies or be due to routine spacecraft maintenance requiring sensor switch-off.
